A target flow switch used to control indoor commercial central air conditioners (water coolers)
Product Introduction
It is widely used in water systems of chillers and air-conditioning projects. It can ensure the safe and efficient operation of air-conditioning systems. When the water flow changes, the force generated by the water flow on the target causes the lever to rotate, and the control circuit is closed or opened, thereby achieving the purpose of automatic control.
Product Outline Drawing
Product Parameters
| Maximum Glass Tube Length | 24L/min±10% |
|---|---|
| Maximum Glass Tube Diameter | 20W |
| Lead Diameter | AC 230V，DC 48V |
| Contact Form | Less than 1A |
| Maximum Rated Power | Water (water cannot freeze) |
| Maximum Operating Voltage | PN10(0.1MPa) |
| Maximum Operating Current | Maximum +80℃ |
| Sensitivity Range | Maximum +100℃ |
Features
- ● Using Reed Switch type sensor, magnetic control has no power consumption ● High sensitivity and stable action performance ● Using Reed Switch as the sensing element, the product has a long service life ● The sensor turns on and off depending on the flow rate and has nothing to do with temperature and pressure ● The application of the product is relatively flexible and can be selected according to the actual application ● Different mounting joints and adjusting the length of the target variable
